Engine Type: 200CC 4-Stroke, Single Cylinder
Cooling System: Air Cooled
Starting System: Electric Start
Ignition: C.D.I, Battery: 12V 10Ah
Clutch: Automatic CTV With Reverse
Fuel Capacity: 1.75L
Brakes F/R: Both Hydraulic Brakes Disc
Tires F/R: 22x7-10 / 22x10-10
Max Speed: 35 mph
Carburetor Brand: Deli (Vacuum film)
Max HP: 8.2hp/7500rpm
Bore x Stroke: 2.26x2.28 inches
Climbing Ability: 20-25 degrees
Driveline/Driving Wheel: Chain/Dual Wheel Drive
Suspension F/R: Independent Dual A-Arm/Double Oil Damped Shock
Weight: G.W./ 650 LBS/ N.W 528 LBS
Max load: 500 lbs
Wheelbase: 72”£¬Height To Seat: 21”
Carton Dimensions: LxWxH : 90”x52”x32”
Min Ground Clearance: 6.3”
Colors: Black, Blue, Red, Yellow, White
